POCKET SLIDING SYSTEM

The pocket sliding system represents a modern, useful and aesthetically attractive solution. Thanks to this elegant solution a separation of two rooms in less spacy interior is possible. When doors are open the door wing stays hidden in the pocket that is mounted into the wall, so the surrounding space can be used for another purpose than for door opening. The pocket sliding system can be used in roomy interiors as well. It will represent an original and ingenious solution how to connect two rooms in effective way.

Pocket sliding set contains: a door wing and frame adjusted for sliding, fitting (lock, pull).

¨

Standard	Komfort	Unibox	Parallel
Basic kind of pocket for single doors	Set of two pockets that are connected with a special bar that is mounted at the top of the system and that enables movement of doors. This synchronized mechanism of door sliding is included in the price of pocket.	Set of two pockets where both doors are pushed (during opening) to the same space between these building apertures, so they are hidden in the surrounding wall consecutively.	Kind of building aperture for double doors that are going to be open in the same direction. Then both doors stay in parallel in the surrouding wall.

Details:

Door frames - precise design
Door frame is an inseparable part of the pocket sliding system and its function is mainly aesthetical. This door frame covers particular building aperture and the rail of sliding system. The door frame is offered in the same decors as doors (different décor on request). Two kinds of door frames can be purchased (asymmetrical or symmetrical). The main difference between these two kinds is that the symmetrical frame isn’t oriented to any side. As far as the asymmetrical frame is concerned, you have to choose a side to which the frame should be oriented.

• Stopper and special separated jamb. The door frame is mounted from several compoments including a special separated jamb and stopper. Bars of the stopper are going to create a pocket into the jamb that serves for door closing. The stopper is included only for single doors, double doors are delivered without this component, but are equiped with 2 pcs. of special separated jamb.
• Special separated head jamb and casing. These two accesories have mainly design function. They are going to cover the construction of door pocket. Space between jamb and wall is covered with set of casing that enables to adjust the frame according to the thick of wall. Be carefull, any size of the door frame can be adjusted only of limited amout of milimetres.


Door wing - unlimited supply of décors and models
The sliding doors are produced as non-rebated. At the bottom of the door wing there is a groove that is normally connected with the floor trail. The floor trail guarantees a narrow movement of the door wing.

Accessories - useful helpers

• Pull. The pull represents a substitute to conventional kinds of door handle. The pull is located inside the door wing, so it doesn’t disturb during opening of the doors.
• Lock. As far as the wall sliding system is concerned its lock is based on hook principle. This hook is going to be stuck in the door striking when these doors are locked. Sliding doors are delivered with interior common, WC or cyllindric lock.
• Front handle. Front handle at front side of the door wing is given up to door opening, especially when the door wing stays totally hidden in the pocket. Front handle: 100 Czk/ door wing.
• Brushes represent one of the accessories for the door frame. They are mounted at the top and bottom side of the door wing. Brushes are going to fill a gap between the door wing (closed) and door frame. Another purposes of this accessory are better acoustic isolation and less dust swirling. Brushes: 100 Czk/ door wing.
